CMP10X
The CMP10x combines analogue heritage with unmatched stability. Built on CMP10, it ensures low instrument drift over long-term use, integrated thermistor for temperature compensation, and durable design for extreme conditions.
Enquire about this productKey features
- ISO 9060 Secondary Standard
- No desiccant inspection or change for 10 years
- Minimised maintenance
- 5 year full warranty *
- Lowest cost of ownership
- Best price / performance ratio
- Proven technology
The CMP10x is the spectrally flat Class A pyranometer with the best price-quality-performance ratio on the market. The CMP10x provides a quality irradiance measuring solution for applications where maintenance is difficult and/or forms a major part of the cost of ownership.
The CMP10x has an internal drying cartridge that will last for at least 10 years if the housing is not opened. This minimizes maintenance significantly.
The interval for dome cleaning can be extended, and the quality of measurements maximized, by fitting CMP10x with the proven CVF4 ventilation unit.
The Pyranometer does not require a dedicated power supply. It generates a low voltage output in the estimated range of 0 to 21 mV relative to an irradiance measurement range of 0 to 1500 W/m². When a higher voltage level or a 4 to 20 mA signal is required, the AMPBOX is the perfect solution.
Technical specification
| Spectral range (50% points) | 285 to 2800 nm |
| Sensitivity | 7 to 14 µV/W/m² |
| Response time | < 5 s |
| Zero offset A | < 7 W/m² |
| Zero offset B | < 2 W/m² |
| Directional response (up to 80° with 1000 W/m² beam) | < 10 W/m² |
| Temperature dependence of sensitivity (-10 ºC to +40 ºC) | < 1 % |
| Operational temperature range | -40 °C to +80 °C |
| Maximum solar irradiance | 4000 W/m² |
| Field of view | 180 ° |
